DZW-P32S Hydraulic Hose Crimping Machine, Large Diameter Hose Crimper Factory From China
The P32S CNC Hose Crimping Machine is developed to meet the rigorous demands of professional hydraulic hose fabrication. Adopting a high-standard global component configuration, it maintains stable crimping precision even under prolonged heavy-duty production. Multiple intelligent control modes deliver flexible workflow options, while robust mechanical structure ensures long service life and minimal downtime for your hose assembly workshop.
Main Components
German ARGO-HYTOS Solenoid Valve
Delivers agile hydraulic flow regulation for smooth die motion. It absorbs hydraulic shock and sustains stable pressure through continuous cyclic crimping.
Taiwan DingZing Sealing Kit
Withstands persistent high hydraulic pressure, prevents internal oil leakage and stabilizes system performance to extend maintenance cycles.
Siemens Drive Motor
Outputs stable torque under heavy continuous loads. Uniform crimp power avoids dimensional deviations during bulk hose manufacturing.
France Schneider Electric Parts
Forms interference-resistant control circuitry. Reliable signal conduction minimizes unplanned downtime and improves overall operational stability.
Japan Omron Control Switches
Enables fast precise command response and solid safety interlock protection, securing dependable operation in each crimping cycle.
Turkey Opkon Precision Sensor
Real-time position monitoring maintains consistent crimp sizing batch to batch, delivering high repeatability and reducing defective products.
Detailed Parameters
Max Criming Dia | 87mm / 3.42 inch | Max Crimping Force | 2000 KN/200 Tonnage |
|---|---|---|---|
| Hydraulic Hose Size | Up to 2 Inch | Industrial Hose Size | Up To 3.42 Inch |
| Max Opening | + 33mm Total Travel | Master Die Size | 99/80 mm (3.90/3.15 inch) |
| Motor Power | 4 KW | Oil Tank Volume | 43 L |
| Machine Dimensions | 840×600×1400 mm | Machine Weight | 286 Kg /631 lbs |
Mold Parameters
| Die Set No | D（mm） | L（mm） | L（mm） |
| P32/06* | 6 | 55 | 6.8-8.0 |
| P32/08* | 8 | 55 | 8.0-10.0 |
| P32/10* | 10 | 55 | 10.0-12.0 |
| P32/12* | 12 | 55 | 12.0-14.0 |
| P32/14 | 14 | 55 | 14.0-16.0 |
| P32/16 | 16 | 55 | 16.0-19.0 |
| P32/19 | 19 | 55 | 19.0-22.0 |
| P32/22 | 22 | 70 | 22.0-26.0 |
| P32/26 | 26 | 70 | 26.0-30.0 |
| P32/30 | 30 | 70 | 30.0-34.0 |
| P32/34 | 34 | 75 | 34.0-39.0 |
| P32/39 | 39 | 75 | 39.0-45.0 |
| P32/45 | 45 | 90 | 45.0-51.0 |
| P32/51 | 51 | 90 | 51.0-57.0 |
| P32/57 | 57 | 100 | 57.0-63.0 |
| P32/63 | 63 | 100 | 63.0-69.0 |
| P32/69 | 69 | 110 | 69.0-74. |
| P32/74* | 74 | 110 | 74.0-78.0 |
| P32/78* | 78 | 110 | 78.0-84.0 |
*: Non standard die
Key Advantages
CNC Digital Precision Control
Adopts new CNC digital crimping control, achieving precise control within 0.1 mm and maintaining accurate results even after long‑time continuous operation.
Long‑Term Reliable Warranty Support
Backed by 4‑year machine warranty, brings reliable after‑sales guarantee for heavy‑duty daily production.
Efficient Working Cycle
Short working cycle: only around 12 seconds from full closure to full opening, supports high‑volume continuous hose production.
Fast Mold Replacement Structure
Quick‑change tool and die rack greatly shortens die swapping time, suitable for frequent specification switching in batch workshops.
Adjustable Crimping Delay & Opening Setting
Features crimping delay and opening‑size setting functions, users can configure crimping parameters according to different hose requirements.
Dual‑level Safety Protection
Comes with stop‑function die‑open button and emergency‑stop power‑cut button, providing double safety protection for daily machine operation.
Product Gallery
Frequently Asked Questions
It can reliably crimp up to 2" 6SP hydraulic hoses. Its high crimping force remains stable even during long‑hour heavy‑load batch production for high‑pressure hose assemblies.
The CNC digital control maintains consistent crimping accuracy in extended runs. High‑grade core components reduce thermal‑drift influence to keep dimensional error within the 0.1 mm requirement.
Service life mainly depends on crimping frequency, hose pressure grade and daily lubrication.
The quick‑change die rack is built for frequent specification switching with proper routine maintenance.
Yes. Combined with CNC digital control and quick‑change die structure, it reduces manual adjustment errors when switching hoses, delivering repeatable crimping quality across various hose types.
Regular hydraulic‑oil inspection, sealing‑part check and proper die‑rack lubrication are required.
Following recommended maintenance procedures helps keep valid 4‑year warranty support.
This 12‑second cycle time is tested under actual typical workshop operating conditions, reflecting real production efficiency for standard high‑pressure hydraulic hose crimping jobs.
