DZW-P32A Hydraulic Hose Crimping Machine, Large Diameter Hose Crimper Factory From China
The P32A hydraulic hose crimping machine is a heavy-duty industrial crimper designed for hydraulic hose assembly factories and equipment maintenance enterprises. It delivers powerful crimping capacity to process hydraulic hoses up to 2-inch 6SN/6SP steel reinforced hose. Built upon a global premium component supply chain and human-centered safety operation framework, this model is engineered to sustain uninterrupted mass production workloads.
Widely deployed within construction machinery, hydraulic fitting manufacturing, oil & gas and vehicle maintenance sectors, it has gained consistent positive feedback from international hose fabricators. Every machine undergoes comprehensive factory calibration and rigorous testing to maintain steady, long-lasting performance under daily heavy-load operation.
Main Components
German ARGO-HYTOS Solenoid Valve
Enables precise real-time adjustment of hydraulic pressure and flow, maintaining stable operation under prolonged high-pressure cyclic conditions.
Custom Taiwan DingZing Seals
High-quality DingZing sealing elements withstand repeated pressure fluctuations, effectively blocking hydraulic oil leakage inside the hydraulic circuit.
Siemens Custom Drive Motor
High-efficiency Siemens motor outputs consistent driving power, supporting reliable non-stop operation for high-volume hose assembly production.
France Schneider Electric Components
Established Schneider electrical assemblies offer strong anti-interference performance and improve the overall stability of the control system.
Japan Omron Control Switches
Dependable Omron switches ensure accurate signal response for operation commands and safety interlock functions during every crimp cycle.
Turkey OPKON Precision Sensors
High-precision OPKON sensors monitor movement status in real time to achieve repeatable, uniform crimp dimension control.
Detailed Parameters
| Max crimping dia | 87mm / 3.42 inch | Max Crimping Force | 2000 KN / 200 Tonnage |
|---|---|---|---|
| Hydraulic Hose Size | Up to 2 inch | Industrial Hose Size | Up to 3.42 inch |
| Max Opening | +33 mm (Total Travel) | Master Die Size | 99/80 mm (3.90/3.15 inch) |
| Motor Power | 4KW (1-phase/3-phase) | Oil Tank Volume | 43 Liters |
| Machine Dimensions | 840×600×1400mm | Machine Weight | 286kg / 631 lbs |
Mold Parameters
| Die Set No | D(mm) | L(mm) | Crimping Range(mm) |
| P32/06* | 6 | 55 | 6.0-8.0 |
| P32/08* | 8 | 55 | 8.0-10.0 |
| P32/10* | 10 | 55 | 10.0-12.0 |
| P32/12* | 12 | 55 | 12.0-14.0 |
| P32/14* | 14 | 55 | 14.0-16.0 |
| P32/16* | 16 | 55 | 16.0-19.0 |
| P32/19* | 19 | 55 | 19.0-22.0 |
| P32/22* | 22 | 70 | 22.0-26.0 |
| P32/26* | 26 | 70 | 26.0-30.0 |
| P32/30* | 30 | 70 | 30.0-34.0 |
| P32/34* | 34 | 75 | 34.0-39.0 |
| P32/39* | 39 | 75 | 39.0-45.0 |
| P32/45* | 45 | 90 | 45.0-51.0 |
| P32/51* | 51 | 90 | 51.0-57.0 |
| P32/57* | 57 | 100 | 57.0-63.0 |
| P32/63* | 63 | 100 | 63.0-69.0 |
| P32/69* | 69 | 110 | 69.0-75.0 |
| P32/74* | 74 | 110 | 74.0-78.0 |
| P32/78* | 78 | 110 | 78.0-84.0 |
*: Non standard die
Key Advantages
High Pressure Crimping Capacity
Supports powerful crimping for hoses up to 2", compatible with 110V / 220V / 380V power supply options to suit different workshop power standards worldwide.
Extra Wide Opening
Features an impressive maximum opening of 132 mm, facilitating easy loading and removal of large-size hose assemblies.
Ultra-Fast Working Cycle
Completes one full crimp cycle within only 6 seconds, greatly lifting daily production throughput for mass assembly tasks.
Dual Safety Protection Mechanism
It adopts dual safety design: the die-open button has stop function, paired with power-cut emergency stop to protect operators.
Precise Crimping Control
Maintains crimp tolerance within 0.1 mm, ensuring highly consistent finished dimensions for every hose fitting.
Low-Noise Hydraulic Performance
Fitted with customized high-pressure oil pump. It delivers strong hydraulic force while generating minimal operational noise for a comfortable working environment.
Product Gallery
Frequently Asked Questions
It outperforms welded-head crimpers with a high-hardness, wear-resistant one-piece forged head.
Paired with Taiwan DingZing seals, it prevents oil leakage and ensures a longer service life under heavy loads.
We adopt German ARGO-HYTOS valves because ordinary valves are unstable under high pressure. They deliver precise pressure control and avoid failures during frequent long-term hydraulic cycles.
It is safer due to premium electrical configurations. Equipped with Siemens emergency stop buttons and Schneider Electric components, it supports dual safety: mold opening stop and power-off emergency stop to eliminate operation risks.
It adapts to frequent size changes thanks to high-precision OPKON sensors. They provide real-time position feedback to maintain stable crimping accuracy and improve production efficiency.
We use high-strength custom fasteners because standard screws loosen from vibration.
They keep the machine structure stable, reduce maintenance and extend equipment service life.
It wins global recognition not only for full premium configurations, but also for its stable crimping precision,
fast cycle speed and durable overall structure. Reliable long-term working performance brings great value to mass production.
